Bafang BBS02B kit 48V 500W/750W with 48V Hailong 01/G70 battery

Availability: In Stock

$646.00

Brand: Bafang

* Required Fields

Overview

Quick Overview

8FUN/Bafang bbs02B kit 48V750W, 48V500W and 48V11.6AH, 48V13.4AH, 48V13.8AH or 48V15AH Hailong 01 downtube battery. battery fixing plate are included.  Bafang has upgraded bbs kits to be BBS01B and bbs02B for better waterproofing. Installation tools are included with the shipment.

 If your needs longer cords for installing the BBS kit, we have BBS EB-BUS extension cordspeed sensor extension cableLCD extension cablebrake/throttle extension cable as well.

Description

Details

Packing list for the kit:

1. Bafang BBS02B central driven motor kit 48V 750W or 48V 500W

2. C961, C965, DPC18 , SW102, 500C LCD display

3. Brake lever in silver color

4. EB-Bus waterproof cable

5. Fixing plates

6. Chain wheel(44T, 46T, 48T and 52T for option) and chain cover

7. Crank

8. Speed detecting sensor and magnets

9. Related nuts

10. Thumb throttle

11. 48V11.6Ah, 13.4AH, 13.8Ah, 15Ah down tube battery for options,  this battery is newly designed and installed on bicycle bottle cage position

12. Power cable with plug soldered and fixing plate for battery

13. You can choose C965 or C961 LCD meter

14. The installation tools are included, one M33 spanner and Allen key set.

 15. Wuxing headlight QD-139-2, horn and DK11 switch for your option; If you want to connect the headlight and taillight directly to the bbs motor, we can also provide: Bafang mid motor 6V LED front light and bafang LED taillight

16. If your bike has derailleur system, you can choose our BBS gear sensor for the kit.

Note:

1. Assembling and testing the battery would take a few days, therefore the leadtime for this item is about 7 days, please be noted.

2. For long time hill-climbing or long distance up-hill roads, please use PAS function of the kit, otherwise the discharging connector of this battery case(two pin air plug) would too heat.

3. If you want to keep your existing brake system, you can choose brake sensor; if your brake system is hydraulic brake, you can choose hydraulic brake sensor.

Additional Info

Additional Information

dimension 361x90x91mm or 362x90.3x109.4mm for battery
net weight 10.98
Manufacturer Bafang
